Electrocardiograph
Item#：W00001265
Brand：EHSY
Origin：China
Description Tech Specs Shipping Detail Certification Accessories
Westingarea supplied high quality has the excellent performance displayed as：
Features:
- Portable, lightweight design
- Easy data input and operation
- Alphanumeric keyboard and one-touch operation
- Built-in rechargeable battery, AC/DC power supply
- Pacemaker detection which meet the requirements of ANSI/AAMI EC11
- Automatic analysis and diagnostic software for adults and pediatrics
- Two-step exercise test with periodic recording
- Heart rate variability (HRV) analysis
- Internal thermal printer and external printer
- Support external archiving: USB flash disk, card reader
- Data transmission to PC via Ethernet or serial port
| Item： | Electrocardiograph | |
| Input circuit： | Defibrillation protection built-in | |
| Lead： | Standard 12 leads | |
| Acquisition mode： | simultaneous 12 lead acquisition(10-24s adjustable) | |
| A/D converter： | 24 bits | |
| Sampling rate： | 1000Hz/channel, 10000Hz for pacemaker detection | |
| Input voltage range： | ±5mVp-p | |
| Time constant： | >3.2s | |
| Frequency response： | 0.05Hz-150Hz | |
| Calibration voltage： | 1mV±2% | |
| Input impedance： | >50MΩ |
This item does not require any certification.
No Accessories!
